Seeed Studio Grove – Oxygen Sensor(ME2-O2-Ф20)

Grove Oxygen Sensor(ME2-O2-20) is a kind of analog gas sensor to test the oxygen concentration in air, which is based on the principle of the electrochemical cell to the original work. You can know clearly the current oxygen concentration when you output voltage values proportional to the concentration of oxygen and refer to the oxygen concentration linear characteristic graph.

This Grove O2 sensor can be used to make simple oxygen-level detectors and analyzers. It can measure O2 concentration within a range of 0 to 25% Vol and the max detecting concentration is 30% Vol. Its very suitable for detecting oxygen concentrations in the Arduino environment project.

Applications:

• Oxygen Analyzer
• Air Purifier
• Environmental Monitoring

Features:

• High precision
• High sensitivity
• Wide linearity range
• Strong anti-interference ability
• Extraordinary reliability and stability

Specifications:

• Input voltage: 3.3V / 5V
• Detection gas: O2
• Measurement Range: 0~25%Vol
• Max detecting concentration: 30%Vol
• Sensitivity: (0.1 ~0.3 mA ( In air
• Response time: T 90 15 S
• Load resistance: recommended 10 k
• Repeatability:2 output value
• Stability (/month): <2
• Zero drift: 20 40 0.1%vol
• Storage temperature 20 50
• Storage: Humidity: 0 9 9 RH
• Pressure range: normal atmosphere10%
• Weight: G.W 0.033g
• Battery Exclude

Package Includes:

1 x Seeed Studio Grove Oxygen Sensor(ME2-O2-20)
