RHEF100 30V 1A Tyco Raychem PPTC Resettable Fuse

The RHEF series devices offer a high operating temperature (up to 125C) and the broadest range of hold currents available in the radial-leaded form factor (70mA to 15A). The RHEF series devices can also be advantageous for use in standard operating temperatures of up to 85C because they have a flatter thermal derating curve than other radial-leaded devices. Over the same temperature range, the trip-to-hold ratio is lower for an RHEF device compared with other PPTC devices.

Features:

• Resettable and single-use overcurrent devices
• Wide range of form factor and termination methods
• Devices compatible with high-volume electronics assembly

Applications:

• Consumer and Industrial
• Satellite video receivers
• Industrial controls
• Transformers
• Computer motherboards
• Modems
• USB hubs, ports and peripherals
• IEEE 1394 ports
• CD-ROMs
• Game machines
• Battery packs
• Phones
• Fax machines
• Analog and digital line cards
• Printers

Datasheet:-

Download
