Nextion is a Seamless Human Machine Interface (HMI) solution that provides a control and visualization interface between a human and a process, machine, application, or appliance. Nextion is mainly applied to the IoT or consumer electronics field. It is the best solution to replace the traditional LCD and LED Nixie tubes. With the Nextion Editor software, users are able to create and design their own interfaces for Nextion display.
The Nextion Enhanced series are more powerful compared to the Nextion Basic series. It has a faster MCU clock, built-in RTC, 1K EEPROM for user data, 8 digital GPIO, larger flash capacity, and more RAM.
Â
Features:
- Nextion Type: Intelligent Series
- Nextion Models: NX8048K070-011R (18.1 cm resistive touchscreen with enclosure)
- Built-in RTC support (Battery type: CR1220)
- Operating Voltage:5V-7V
- Operating Current: 510mA(VCC=+5V, Brightness is 100%).
Package Includes:
1 x Power Supply Test Board
1 x Nextion 18.1 cm (7 inch) Enhanced NX8048K070-011R HMI Resistive Touch Display with enclosure
1 x XH2.54 4P Wire
4 x Mounting Buckle & Screw
Specifications :-
| Model Name | NX8048K070-011R |
| Colour | 64K 65536 colors |
| Layout size | 18.1 cm(L) x 10.8 cm(W) x 0.93 cm(H) |
| Resolution | 800 x 480 pixel |
| Touch type | Resistive |
| Touches | > 1 million |
| Backlight | LED |
| Backlight lifetime (Average) | >30,000 Hours |
| Brightness | 230 nit |
| RAM | 8192 BYTE |
| FLASH Memory | 32 MB |
| Instruction Buffer | 1024 BYTE |
| User Storage | 1024 BYTE |
| Weight | 598g |
* Product Images are shown for illustrative purposes only and may differ from actual product.
