GSM 4G/3G/2G 6/7 dBi Dual Band LTE Flexible Magnetic Mount Antenna

This is GSM 4G/3G/2G LTE Flexible Magnetic Mount Antenna having Frequency of 698 960 MHz & 1710 2690 MHz and 6/ 7 dBi Gain.

This antenna is supported to GSM FCT of Micromax, and other GSM Module/Modems. Magnetic mount antennas are commonly used for car and truck applications. The antennas magnetic base sticks securely to the metal of the vehicle. The metal surface of the car acts as a ground plane to bounce the signal. Since magnetic mount antennas require a ground plane, they should be mounted on metal.

 GPRS, GSM, 3G,4G, ISM

Application:

Features:

Magnetic base indoor antenna.

High quality

low cost.

20 x 2 mm Neodymium powerful magnets.

Chrome-plated available for 1K+ order quantity.

Package Includes:

1 x GSM 4G/3G/2G LTE Flexible Magnetic Mount Antenna

Specifications :- Frequency (MHz)698 960 MHz & 1710 2690 MHz Gain6/ 7 dBi (with 1m cable) Impedance ()50 VSWR< 2.5 PolarizationLinear Power Handling (W)50 HPBWH: 3600 ; V: 300 / 400 ConnectorSMA-PLUG or as required Operational Temperature-30 to 60 C Humidity5 75% HousingSpring Steel Powder Coated Dimension (mm)310 x 27 Weight75 g (depends on cable length)

* Product Images are shown for illustrative purposes only and may differ from actual product.
